ABJ Liquid-Gas Fuel Steam Generators Liquid - General Features
It complies with TS EN 12953-1-3, TS 377-1-2-3-4-5-6-7-8- 10-11-12-14, TS EN 12953-1-2-3-4-5-6-7-8-10-11-12- 14 standards.
It produces needed pressure in a very short time.
It has been manufactured from three-transitional nested steel drawn pipe as spiral serpentine.
It has been exploited from the energies at maximum level by making 3 transitions for gases.
It has full automatic combustion control system.
Thanks to compact type electrical remote control panel, it ensures sound and light warning for the defects.
Generator outer body is isolated as oven-drying sheeting on stone wool with high density.
Depending on the fuel options, it operates with liquid and gas fuel burner without problem.
It provides operation fl exibility with steam separator and it ensures to obtain dry steam.
It is manufactured with computer aided design and manufacturing technology in accordance with CE quality standards, TRD pressure vessels directive, EN, TSE standards.
BFPN: 153.3100, 3 are liquid-gas fuel boilers made from steam producer steel material under 3 atm construction pressures.
BFPN: 153. 3400, 6 are liquid-gas fuel boilers made from steam producer steel material under 6 atm construction pressures.
